used Industrial robot arm YASKAWA MotoMINI for pick and place 0.5kg Payload 350mm Arm robots
Main Specifications:
Model:MotoMINI
Maximum reach:350mm
Maximum payload:0.5kg
Pose repeatability:± 0.02mm
Number of axes:6
Weight:7kg
Equipped with the highest acceleration in a small robotic arm, the MotoMini is 20% faster than comparable small robots, reducing cycle time and boosting productivity. Internal cabling and air lines minimize interference with other process equipment, and a variety of mounting options (surface, wall, ceiling, etc.) accommodate high-density factory layouts. Designed for extremely agile, high-speed performance for a wide range of applications, the quiet, compact and precise MotoMini can take your small-part process to the next level.
| Product Name | Industrial robot arm YASKAWA MotoMINI for pick and place 0.5kg Payload 350mm Arm robots |
| Model | MotoMINI |
| Application | Handling & Assembly |
| Maximum reach | 350mm |
| Maximum payload | 0.5kg |
| Pose repeatability (ISO 9283) | ± 0.02mm |
| Number of axes | 6 |
| Mounting position | Floor, ceiling, wall, tilt |
| Weight | 7kg |
| Protection rating | IP67 |
| Controller | YRC1000 controller micro |
| Motion range | |
| S | 170° to -170° |
| L | 90° to -85° |
| U | 90° tp -50° |
| R | 140° to -140° |
| B | 210° to -30° |
| T | 360° to -360° |
MotoMINI Introduction:
The MotoMINI 6-axis robot was especially designed for handling and assembly of small work pieces. It reduces the size of your production line and helps to increase productivity.
This light weight high-speed robot provides a payload of 500 g and a maximum reach of 350 mm. The high repeatability of 0.02 mm offers superior performance in small part handling and assembly. It is easy to change the location of MotoMINI according to the line’s operating condition or the work piece being manufactured.
This robot is driven by the also small and compact MOTOMAN YRC1000micro controller, which is especially suited to operate small robots.
KEY BENEFITS
• Small and fast
• Lightweight and portable
• Superior performance in small part handling & assembly
• Minimum footprint
• Flexible positioning
Applications:
Handling & Assembly
|
|
